alloy steel round bar suppliers / supplier of alloy steel round bar / alloy steel round bar manufacturer

Alloy Bright Bar, Alloy Steel Bar, ASTM A182 Alloy Round Bars, Alloy Steel Flat Bar, Chrome Moly Rods Suppliers and Dealer in Mumbai, India.

Alloy Steel Round Bars & Rods Suppliers & Exporters / Alloy Steel Round Bars| f5 f9 f91 Round Bars in India.

About Us:

IMC stocks a full range of Alloy Steel Round Bars, ASTM A182 F1, F2, F5, F9, F11, F22, F91 Alloy Steel Round Bars in its many shapes, forms and grades and also supplies Alloy Steel Round Bar to order to meet your specific requirements.

availability of our Alloy Steel stock.

Alloy Steel BS970 605M36 / 606M36 (EN16 / EN16M
Alloy Steel BS970 708M40 / 709M40 (EN19)
Alloy Steel BS970 817M40 (EN24)

Specification :

Standard	:	ASTM / ASME A/SA 182, ASTM A276, ASME SA276
Rods Range	:	4 mm to 350 mm dia
Wires Range	:	0.5 mm to 10 mm dia
Grade	:	A-182 - F5, F9, F11, F12, F21, F22 & F91
Diameter	:	10 mm To 200 mm Diameter
Form	:	Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Finish	:	Rolled Black Bars, Bright Bars, Forged Bars, Polished Bars, 2B, 2D, BA, MAT

Equivalent Grades of Alloy Steel Bars, Rods & Wires:

STANDARD	UNS	WNR.
Alloy Steel F5	K41545	-
Alloy Steel F11	K11597	1.7335
Alloy Steel F22	K21590	1.7380
Alloy Steel F91	K90901	1.4903

Chemical Compositions of Alloy Steel bars, Rods & Wires:

Element	C	Cr	Mn	Mo	P	S	Si	Ni
F1	0.15 Max	3.0-5.0	0.30-0.60	0.40-0.50	0.035 Max	0.030 Max	0.50 Max	0.50 Max
F5	0.15 Max	4.0-6.0	0.30-0.60	0.44-0.65	0.035 Max	0.030 Max	0.50 Max	0.50 Max
F9	0.15 Max	8.0-10.0	0.30-0.60	0.90- 1.10	0.030 Max	0.030 Max	0.50- 1.00	-
F11	0.10-0.20	1.00-1.50	0.40-0.65	0.44-0.65	0.025 Max	0.040 Max	0.50-0.80	-
F22	0.05-0.15	2.00-2.50	0.30-0.60	0.90-1.10	0.035 Max	0.040 Max	0.50 Max	-
F91	0.08-0.12	8.0-9.5	0.30-0.60	0.85-1.05	0.020 Max	0.010 Max	0.20-0.50	0.40 Max

Mechanical Properties of Alloy Steel Bars, Rods & Wires:

grade	Tensile Strength (ksi) min	Elongation (% in 50mm) min	Yield Strength 0.2% Proof (ksi) min	Hardness
F5	275	485	20	-
F9	415	30	205	-

Types Of Alloy Steel Bars, Rods & Wires :

•   Alloy Steel Cold Drawn Bars •   Alloy Steel Hex Bars •   Alloy Steel Wire •   Alloy Steel Bright Bars •   Alloy Steel Spring Steel Bars •   Alloy Steel Wire Bobbin •   Alloy Steel Wire Coil •   Alloy Steel Filler Wire

•   Alloy Steel Bars •   Alloy Steel Rods •   Alloy Steel Hollow Bar •   Alloy Steel Black Bars •   Alloy Steel Forged Round Bars •   Alloy Steel Square Bars •   Alloy Steel Threaded Bars •   Alloy Steel Hexagon Bars





Please note that we are the largest and specialist stockists of Alloys Steel Pipes, Tubes and Alloy Steel Plates in India.
ALL PIPES, TUBES & PLATES ARE AVAILABLE WITH ORIGINAL MILL TEST CERTIFICATE & IBR CERTIFICATE
